Octagon SX98 V2 4K WL UHD Linux 1x DVB-S2 Sat IP Receiver (Dolby Digital+, Dual WiFi, LAN, CA)

The Octagon SX98 V2 4K WL sets new standards in the field of satellite receivers and offers you an incomparable television experience. With its razor-sharp 4K UHD resolution and a high-performance 15,000 DMIPS ARM Cortec-A55 quad-core processor and the customizable Linux (Define OS) operating system, this receiver is well equipped to meet your most demanding entertainment needs.

Features
- 4K UHD (3840 x 2160p) Resolution
- Linux Operating System
- 1GB DDR3 RAM & 8GB Flash
- Dual-Band WiFi 5
- CA Card Reader

Flexibility & Adaptability
The strength of the SX98 V2 4K WL lies in its software flexibility. Thanks to the support of images, plugins, add-ons and skins, you can customize the receiver according to your personal preferences and needs. Whether you want to add additional features, change the user interface or install special codecs, the possibilities are almost endless.

PVR via USB
PVR via USB (Personal Video Recorder via USB) is a feature that allows you to record TV shows to an external USB storage device, such as a hard drive or USB stick.

Technical Info
- Product type: Sat IP receiver
- Image: UHD 4K
- Image resolution: 3840 x 2160p
- Video Codec: HEVC/H.264, HEVC/H.265, MPEG-2, MPEG-4, VP9
- Audio Codec: AAC, AAC Plus, MP3, Dolby Digital, Dolby Digital Plus, DTS, TureHD
- Operating System: Linux (Define OS)
- SoC: 6323V100
- CPU (Processor): 1,600 MHz ARM Cortex-A55 Quad-Core
- GPU (Graphics): ARM Mali-450
- RAM: 1GB DDR3
- Flash Memory (flash): 8GB
- DMIPS: 15,000
- DiSEqC 1.0/1.1/1.2, USALS
- PVR: Yes via USB
- Tuner: 1x DVB-S2
- Tuner Type: Satellite Tuner
- HD+ Support: No
- HDMI CEC Support
- Remote Control: IR remote control
- Internet Radio
- OSD user interface can be customized in many ways (skin support)
- Media libraries of public broadcasters
- Web interface touch & FTP
- Extended EPG (electronic program guide)
- DLNA player & media player with recording & time shift function
- Unlimited creation of favorites lists
- Multiroom client & Sat to IP client support

Connections
2x USB 2.0
1x HDMI 2.0a
1x LNB Input
1x AV Connection
1x DC Connection
1x IR Connection
1x S/PDIF (Optical)
1x CA Card Reader
1x LAN (10/100Mbit/s)
1x Recovery (Reset) Button Service & Maintenance

Connectivity
- LAN: 10/100 Mbit/s (Fast Ethernet)
- WLAN: 2.4/5.0 GHz Dual-Band WiFi
- WLAN (Standards): WiFi 5
- WLAN (Speed): 1200 Mbit/s

Device
- Power Supply: DC 12V 1.5A
- Power Consumption (standby): 0.5W
- Power Consumption (operation): Max 20W
- Storage Temperature: 0 40°C
- Humidity: <95%
- Dimensions: 148 x 103 x 30 mm
- Product Weight: 250 g
- Package Weight: 660 g
- Color: Black
- Country of Origin: China

Delivery
1x Octagon SX98 V2 4K WL UHD Linux 1x DVB-S2 Sat IP Receiver
1x Octagon SFX RCU 03 IR Remote Control, Black
1x External Infrared (IR) Receiver
1x HDMI Cable
1x Power Supply
2x Batteries (AAA)
1x Operating Instructions

Item no.: RECOCT145

WEEE-Number 69966297
